Polyester Felt Bag Filters

SP-BE Series

SpiroPure SP-BE series liquid bag filters are composed of polyester felt filter media. Polyester felt offers a high dirt loading capacity and reliable filtration performance. Polyester felt bag filters are particularly suited to applications that require a high temperature tolerance and low moisture, such as filtration for food manufacturing, metalworking, woodworking, and energy filtration.

Filter has an economical high dirt-holding capacity for a broad range of filtration applications
Available in sizes: #1, #2, #3, and #4
Available nominal filtration ratings of: 1, 5, 10, 25, 50, 100, and 200 microns
All SpiroPure polyester felt bag filters have a max temperature rating of 176°F

buy online
Specifications Sheet

Filter Details Chart
	Model #	Nominal Micron Rating	Temperature Rating	Case Quantity	Case Dimensions	Case Weight
#1	SP-BE-1-1 SP-BE-1-5 SP-BE-1-10 SP-BE-1-25 SP-BE-1-50 SP-BE-1-100 SP-BE-1-200	1 micron 5 micron 10 micron 25 micron 50 micron 100 micron 200 micron	＜ 176°F (80℃)	40	23.5” x 18” x 12”	16 lbs
#2	SP-BE-2-1 SP-BE-2-5 SP-BE-2-10 SP-BE-2-25 SP-BE-2-50 SP-BE-2-100 SP-BE-2-200	1 micron 5 micron 10 micron 25 micron 50 micron 100 micron 200 micron	＜ 176°F (80℃)	40	18” x 16” x 14”	22 lbs
#3	SP-BE-3-1 SP-BE-3-5 SP-BE-3-10 SP-BE-3-25 SP-BE-3-50 SP-BE-3-100 SP-BE-3-200	1 micron 5 micron 10 micron 25 micron 50 micron 100 micron 200 micron	＜ 176°F (80℃)	40	16” x 14” x 10”	7 lbs
#4	SP-BE-4-1 SP-BE-4-5 SP-BE-4-10 SP-BE-4-25 SP-BE-4-50 SP-BE-4-100 SP-BE-4-200	1 micron 5 micron 10 micron 25 micron 50 micron 100 micron 200 micron	＜ 176°F (80℃)	40	23.5” x 18” x 10”	10 lbs
