| Model Number | Nominal Micron Rating | Pressure Drop | Temperature Rating | Case Quantity | Case Dimensions | Case Weight | |
|---|---|---|---|---|---|---|---|
2.5" x 10" |
SP-AP1001 SP-AP110 |
1 micron 5 micron |
0.6 psi @ 5 gpm (<0.04 bar @ 19 Lpm) 0.4 psi @ 5 gpm (<0.03 bar @ 19 Lpm) |
40°F - 145°F (4.4°C - 62.8°C) |
24 |
15 1/2” x 11” x 10 1/2” |
8 lbs |
2.5" x 20" |
SP-AP1001-20 SP-AP110-20 |
1 micron 5 micron |
0.6 psi @ 10 gpm (<0.04 bar @ 38 Lpm) 0.4 psi @ 10 gpm (<0.03 bar @ 57 Lpm) |
40°F - 145°F (4.4°C - 62.8°C) |
20 |
20 1/4” x 14” x 11” |
11 lbs |
2.5" x 30" |
SP-AP1001-30 SP-AP110-30 |
1 micron 5 micron |
0.4 psi @ 15 gpm (<0.03 bar @ 57 Lpm) 0.3 psi @ 15 gpm (<0.02 bar @57 Lpm) |
40°F - 145°F (4.4°C - 62.8°C) |
20 |
31” x 14” x 11” |
19 lbs |
2.5" x 40" |
SP-AP1001-40 |
1 micron |
0.3 psi @ 20 gpm (<0.02 bar @ 76 Lpm) |
40°F - 145°F (4.4°C - 62.8°C) |
20 |
40 1/4” x 13” x 10” |
24 lbs |
4.5" x 10" |
SP-AP810-BB SP-AP811-BB |
5 micron 25 micron |
5.5 psi @ 20gpm (<0.38 bar @ 75Lpm) 4.9 psi @ 20gpm (<0.34 bar @ 75Lpm) |
40°F - 100°F (4.4°C - 37.8°C) |
8 |
20” x 11 1/2” x 10 1/2” |
10 lbs |
4.5" x 20" |
SP-AP810-20BB SP-AP811-20BB |
5 micron 25 micron |
5.5 psi @ 40gpm (<0.38 bar @ 150Lpm) 4.9 psi @ 40gpm (<0.34 bar @ 150Lpm) |
40°F - 100°F (4.4°C - 37.8°C) |
6 |
21” x 15” x 9 1/2” |
14 lbs |
| Size | Rating | SpiroPure | Hydronix | 3M Aqua-Pure |
|---|---|---|---|---|
2.5" x 10" |
1 micron |
SP-AP1001 |
SGC-25-1001 |
3M AP1001 |
2.5" x 20" |
1 micron |
SP-AP1001-20 |
SGC-25-2001 |
3M AP110-2 |
2.5" x 30" |
1 micron |
SP-AP1001-30 |
SGC-25-3001 |
|
2.5" x 40" |
1 micron |
SP-AP1001-40 |
SGC-25-4001 |
|
4.5" x 10" |
5 micron |
SP-AP810-BB |
3M AP810 |
|
4.5" x 20" |
5 micron |
SP-AP810-20BB |
3M AP810-2 |
